Legendary Toyota reliability meets B6 ballistic protection. Saudi-engineered armored platform ideal for high-risk security, VIP transport, and tactical operations.

Delivering Excellence Since 1996

ArmoredTLC79

Legendary Toyota reliability meets B6 ballistic protection. Saudi-engineered armored platform ideal for high-risk security, VIP transport, and tactical operations.

ArmoredTLC79

Overview

File Attachment

No items found.

Specifications

Description

The Armored Toyota LC79 Gibral combines legendary Toyota reliability with advanced B6 ballistic protection. Engineered by ERAF for high-risk security, VIP protection, and tactical operations, this platform delivers uncompromised durability and defense in demanding environments.

Engine & Powertrain

• Engine Model: 4.0L V6 Petrol

• Type: 4 Stroke, 6 Cylinders

• Displacement: 4.0 L

• Max Power: 228 Hp @ 3800 rpm

• Max Torque: 285 Nm @ 2200 rpm

• Fuel Type: Gasoline

• Transmission: 5-Speed Manual

• Transfer Case: Manual

• Clutch Configuration: HD Clutch Upgrade

Dimensions & Geometry

• Overall Length: 5317 mm

• Max Width: 1770 mm

• Max Height: 2725 mm

• Wheelbase: 3180 mm

• Track Width (Front): 1589 mm

• Ground Clearance: 235 mm

• Approach Angle: 41°

• Departure Angle: 33°

Performance & Mobility

• Maximum Speed: 140 km/h

• Range: 1000 km

• Gradeability: 50%

• Side Slope: 40%

• Step Climb Capability: 250 mm

• Fording Depth: 450 mm

Chassis & Suspension

• Front Axle: Upgraded HD Components

• Rear Axle: Upgraded HD Components

• Front Suspension: HD Coil Shock

• Rear Suspension: HD Leaf Shock

• Brakes (Service): Upgraded HD System

• Parking Brake: Cable Operated (Upgraded)

• Steering: Power Assisted Telescopic

• Tires: HD Off-Road with Runflat Capability

• Fuel Tanks: Dual 90L with Kevlar B6 Protection

• Bumper: HD Front Bumper

Ballistic Protection

• Protection Standard: B6 EN 1063 / DM512

• Ballistic Rating: 7.62×39 caliber resistant

• Mine Protection: B6 Level

• Transparent Armor: B6 Ballistic Glass

• Fuel Tank Protection: Kevlar B6 Layer

• Electrical System: 12V DC, Dual OPTIMA Battery 55Ah

• Manufacturer: ERAF Industrial Company Ltd.

• Heritage: Saudi Armored Engineering

Gunports

Fire Extinguisher

Extraction Fan

Fire Suppression System

360° Turret Mount

Core Features

Legendary 4.0L V6 Engine

228 horsepower with 285 Nm torque provides superior power and performance for demanding tactical operations and off-road environments

‍

Complete B6 Ballistic Armor

Full Level B6 protection (EN 1063) across all surfaces including armored transparent panels and fuel tank coverage against 7.62x39 caliber threats

‍

Mine Blast Protection

2× DM51 hand grenade protection with reinforced floor design and shock-absorbing systems for maximum occupant safety

‍

360° Tactical Turret

Integrated weapons platform with full B6 armor protection for mounted weapon systems and precision tactical engagement

‍

Extended Range Capability

Dual fuel tank system (180 liters total) with Kevlar B6-protected tanks provides 1000 km operational range without resupply

‍

Superior Off-Road Capability

Upgraded suspension, dual differential locks, and heavy-duty components enable operation across extreme terrain and challenging environments

‍
